High Flex Cable Solution - Introducing Our Continuous Flexible Wire Mueller Blue-Flex™
Mueller Blue-Flex™ Cable
Patent Pending
Cable Flexibility Beyond Today's Standards
For All Twisting, Bending, Drag-Chain & Robotic Applications
The continuous flex wire, Mueller Blue-Flex™
• Silicone Material • Silicone Jacket Material • 250V • -40°C to 150°C (302°F) • FT2 Flame Test Rating Ultra Flexible, High Temperature Cable • Flex Rating 20 Million Cycles • Torsion Rating 20 Million Cycles
• Made and Shipped from Akron, OH USA
• M12, 3, 4 & 5 pin positions • M8, 3 & 4 pin positions
Introducing the leading continuous flex wire on the market: Mueller Blue-Flex™. Used for all drag chain and robotic applications, our cordsets are designed for flexibility beyond today’s standards, with silicone insulated conductors wrapped in a silicone jacket. Mueller Blue-Flex™ M12 cordsets with pin positions 3, 4, and 5 and M8 cordsets pin positions 3 and 4 all manufactured and shipped from our corporate headquarters in Akron, OH USA.
Muller Blue-Flex™ is offered in silicone material with silicone jacket material for maximum flexibility. Our silicone is ultra flexible with a flex rating at 20 million cycles, a torsion rating at 20 million cycles, a bend radius of Static ≥ 4*OD and Dynamic ≥ 8*OD. Dielectric Test: 2000Vac, no breakdown. Conductor Resistance: 59.4Ω/KM @ 20°C max. It is important to choose the right type of cable for a specific application to ensure that it can withstand the conditions it will be exposed to and provide reliable performance.
Muller Blue-Flex™ connector configuration is male or female with various orientations available in straight, right angle, and open end, unshielded, various lengths, A-coding, and 22 AWG.
Muller Blue-Flex™ instrumentation cable complies with IEC 61076-2-101 Industry 4.0. The voltage rating is 250 V AC/DC and operating temperature is -40° C to 150° C (302° F). Our cables are FT2 flame tested rating , RoHS 3 compliant and IP68 safety rated.
Mueller Blue-Flex™ flexible for constant moving applications in power chains or machine assembly lines. You have to see it to believe it! Request Your Sample Today. Our Mueller Blue-Flex™ cables are made at our headquarters in Akron, OH USA. To become familiarize with our product line for your needs, contact us https://ww2.muellerelectric.com/contact/
